I. Basic Information

Name: Mr. Sun

Gender: Male

Age: 53

Chief Complaint: Mobile maxillary anterior teeth; requesting implant‑supported restoration.

Past Medical History: Denies any systemic diseases, and no known food or drug allergies.

Present Dental History: Mobility of maxillary anterior teeth affecting mastication; presented to our clinic for consultation.

II. Clinical Examination

Intraoral examination was performed.

Radiographic examination was performed.

III. Diagnosis and Treatment Plan

Diagnosis: Mobility of maxillary anterior teeth with periapical abscess and labial alveolar bone resorption.

Treatment Plan: Restoration‑driven approach for the left maxillary (or maxillary anterior) sites, using three Hanzu® implants: one implant (size 3.5 × 15 mm) and two implants (size 4.0 × 13 mm).

IV. Treatment Procedure

Under local anaesthesia, the involved teeth were extracted immediately, and the osteotomy sites were prepared. A mixture of autogenous tooth bone graft and collagen was placed labially to augment the bone defect. Three Hanzu® implants were placed according to the pre‑planned positions.

In April 2025, the prosthetic phase was initiated, and the definitive restorations were delivered.

V. Case Summary

This case involved immediate implant placement at infected extraction sites with purulent discharge, in a patient with osteoporosis and inflammatory infection. The Hanzu® implant system demonstrated strong self‑tapping capability, leading to a favourable clinical outcome.

VI. Clinician Profile

Name: Yan Guangdi

Affiliation/Title: Clinic Director

Honours and Achievements:

Attending Stomatologist (with intermediate qualifications in Prosthodontics and Dental Technology).

Member of the First Committee of the Oral Preventive Medicine Specialty Committee, Henan Preventive Medical Association.

Technical Director of Zhengzhou Yuemeijia Dental Laboratory.

Over 10 years of clinical experience in both dental practice and laboratory fabrication.

Has systematically received formal training in various implant systems from Switzerland, the United States, South Korea, etc., and obtained corresponding certificates; has been engaged in implant dentistry for more than eight years.

Specialises in endodontic therapy, aesthetic restorative dentistry, aesthetic porcelain laminate veneers, functional prosthetic rehabilitation, sinus floor elevation, immediate loading for edentulous arches, minimally invasive implant placement, and minimally invasive tooth extraction.
